[New] AVS 1001HF

uniaxial, digital, high frequency accelerometer

AVS 1001HF

AVS 1001HF is a single-axis, digital, high-frequency accelerometer. In addition to vibrations, it also measures temperature. The sensor measures and processes the vibration acceleration signal. Data is available via a digital connector in the industrial standard RS-485 and the MODBUS protocol. The sensor can provide two types of data: a stream of raw vibration data or determined parameters of the vibration signal.

Applications

Protection

Machine monitoring

Condition assessment

Dynamic state measurements

Technical data

Measurement range

Number of measurement axes

1: Z

Measurement range [g]

± 50, peak

Frequency range [Hz]

0 … 11 000

Electrical data

Operating voltage [V]

24 V DC

Current consumption [mA]

13

Reverse polarity protection

Yes

Type of sensor

Microelectromechanical system (MEMS)

Outputs

Interface

RS485 115 kbps (calculated parameters)
RS485 1.5 Mbps (raw signal)

Maximum number of connected sensors

100

Accuracy / Deviations

Linearity deviation

± 0,1 %

Temperature dependence

± 5 % (-40 °C … +85 °C)

Transverse sensitivity

± 1 %

Noise density

25 µg / √Hz

Operating conditions

Ambient temperature [°C]

-40 °C … +85 °C

Protection

IP67

Tests / Approvals

EMC

EN61326-1:2013

Shock resistance

DIN EN 60068-2-27 100 g 11 ms

Vibration resistance

DIN EN 60068-2-6 20 g / 10 … 3000 Hz

Maximum shock resistance [g]

10 000, peak

Electrical isolation (case)

1 MΩ

RoHS

Yes

CE

Yes

Mechanical data

Dimensions [mm]

Ф 22 x 50,3



Weight [g]

72



Type of mounting

M6 x 7 threaded hole in sensor



Material

Housing: stainless steel

Tightening torque [Nm]

7

Accessories

Accessories

Set screw: M6 to M6

Available separately:
– M6 x 12 mm grub screw
– magnet M6 female, 19 mm, 7kgs

Electrical connection - plug

Electrical connection - plug

AVS 1001HF – Top exit connector: M12 5-pin; maximum cable length: 300 m
AVS 1001HFC – DATAPUR-C 2x2x0,14 QMM; default cable length: 5 m
